80 & RX Series - Short Nose 20º Angle Super Flush Tip Cutters

The Swanstrom 80 and RX Series Short Nose 20° Angle Super Flush Tip Cutters are engineered for ultra-precise cutting in tight, controlled workspaces where accuracy and access are critical. Featuring a short nose design with a 20° angled tip, these cutters provide exceptional visibility and reach, making them ideal for fine electrical work, jewelry fabrication, and precision assembly applications.

Built for professionals who demand clean, consistent performance, the super flush cutting edge delivers smooth, burr-free cuts while minimizing stress on delicate materials. The compact head profile allows for superior maneuverability in confined areas, while maintaining the strength and durability expected from Swanstrom’s RX Series tools.

Specifications

• Handle: Standard
• Head Style: Tip Cutter
• Head Size: Tip
• Cut: Super Flush
• Overall Length: 4.74" (119.38mm)
• Jaw Length: 0.46" (12.7mm)
• Body Width: 0.4" (10.16mm)
• Tip Width: 0.2" (5.08mm)
• Tip Thickness: 0.04"
• Cutter Length: 0.23" (5.08mm)
• Maximum AWG: 20 AWG

With its angled precision tip and refined cutting geometry, this tool is built to deliver maximum control and clean results in the most detail-sensitive applications.
