1/3 hp TX Motor with 60” Square Drive Heavy Duty Shaft & Sheath, TXR Plastic Foot Pedal Speed Control, 115v
Hang-up motor with specialized, square drive shafting plus speed control. A square drive handpiece is required for operation and available separately.
Here our higher torque flex shaft model, the M.TX Hang-up style Motor, is equipped with a longer square drive shaft and heavy duty protective sheath. It is teamed up with a Speed Control of your choice.
Two Year Limited Warranty on Motor and Control.
M.TXH Motor: Foredom’s most powerful flex shaft machines with 1/3HP. This square drive model has the same motor specifications as the M.TX. They have permanent magnet DC motors that feature the latest in flex shaft technology. These ball bearing models utilize advanced rare earth magnets (in place of the wound fields in our universal type Series SR motors) that deliver more torque at the low end and throughout the entire speed range of 500 to 15,000 RPM. Square drive flex shafts are the ultimate power tools for deburring, buffing, grinding, polishing and metal finishing of any kind with larger rotary accessories. They are great for large scale woodcarving and sculpting applications with carbide or steel burs and larger mounted grinding stones.
This model comes equipped with a motor bale for hanging, and a 63″ long, square drive shaft and heavy duty protective sheath. Square drive shafting is heavier and less flexible than standard key tip shafting and works ONLY with Foredom’s 4 square drive handpieces – the H.25H, H. 28H, H.30H and H.44HT.
M.TXH motors are available ONLY in 115 Volt.
C.TXR-1 Speed Control: foot operated speed control is made of heavy duty plastic with durable solid state electronics. The ergonomics allow precise and reliable speed control with your foot. For use with 115 Volt M.TX, M.TXB, M.TXH, M.LX, M.LXB, M.LXH and M.LXBH motors. 7″ long, 4-12″ wide, 2-38″ high, ship wt 2 lbs./1 kg.
Handpieces are available separately and Required to Operate your Flex Shaft Machine. H.25H, H.30H, H.44HT and H.28H are Foredom’s four square drive handpieces that work with this motor-speed control combination and are shown below under Related Products.
Hang-Up style motors require the use of a motor hanger (available separately) to secure the tool above the work bench. See Related Products below.
SHIPPING METHOD: This item must ship via UPS. During the checkout process you may be offered Priority Mail but this item must ship via UPS. If you select Priority Mail, it will only slow down the process as we will have to change the shipping method after the fact and charge the difference. We have learned the hard way to not ship fragile or high value items via Priority Mail.,
Check Out The Foredom Tools Catalog
Foredom Kits and Their Components
Micro-Tools makes every attempt to provide accurate information for each item. Actual packaging and/or specifications may be slightly different from the information and picture provided.
